Description
Small & Compact, HTM Lighting's 30W LED Slim Flood Light has a high efficacy of 130lm/W and is rated for 100-277VAC, which is ideal for small monument signs and architectural lighting.
The 1/2'' Knuckle Mount enables it to be easily mounted onto a standard junction box or ground stake mount.
The 30W LED Slim Flood Light Fixture uses the latest Seoul Semiconductor LED Chips, comes with a standard viewing angle of 7H7V, and is IP65 Rated for Wet Location.
| Type | LED Flood Light | ||
| Item Dimensions | 7.13in. x 1.93in. x 9.18in. | ||
| Wattage | 30W | ||
| Equivalent | 150W MH | ||
| CCT | 4000K-5000K | ||
| Lumens | 3,500 - 4,000 Lm | ||
| CRI | 70 | ||
| Input Voltage | 100-277VAC | ||
| Finish | Bronze |
| Material | Aluminum, PC, Steel |
| Rated Lifetime | 50,000+ Hours |
| Beam Angle | NEMA 7H7V |
| Lens Type | LUXENON 3030 2D |
| Mounting Type | 1/2" Threaded Knuckle Mount |
| IP Rating | IP65 |
| Warranty | 5-Year Limited |
| Certification(s) |
|
Downloads
| Box Qty | 1 |
| Box Dimensions (in.) | 12in x 12in x 4in |
| Box Weight (lbs) | 3.95 lbs |
| Carton Qty | 8 |
| Carton Dimensions (in.) | 19in x 12in x 13in |
| Cartin Weight (lbs) | 27.6 lbs |
